How to send event triggers to Lab Streaming Layer from JsPsych

2026-01-11 · Methods · Róisín Sharma

Hello there! 👋 Let's learn how to send event triggers to Lab Streaming Layer (LSL) from JsPsych.

Lets start with some basics!

What does this mean and when is this useful?

Lab streaming layer (LSL) is a system used to receive, synchronise and stream signals from multiple inputs during experiments. LSL is designed to help researchers easily compare their data across multiple technologies, as time synchrony is integral for making meaningful analyses.

When collecting data on stimulus response during experiments, it's important that the stimulus onset is recorded precisely, especially if this is mapped onto physiological responses as this has implications on how we interpret our data. One good example of a use case is that you have a Muse headband or any other device that can scream via LSL, and you want to precisely mark events in it.

Event triggers are coded into JsPsych online experiments to accurately mark events, such as when a stimulus appeared on the screen. We have found this method to yield the most precise timestamps of events, compared to alternative methods such as using the Bitalino LUX.

This tutorial will explain how to set this up for an experiment situated on GitHub, although you can adapt this for your hosting platform.

This blog will help you understand the set-up for event triggers. For an example of this in action, refer to <https://github.com/OliverACollins/muse-athena-test/tree/main/blackwhite>. This experiment recorded markers on a screen turning from white to black- you may want to follow along with lsl_bridge.py and blackwhite_jspsych.html[^1] for the full implementation.

[^1]: Special shoutout to our placement student Oliver Collins for preparing these scripts!

How to set up event triggers

Requirements

The LSL bridge script

The LSL bridge Python script is responsible for actually sending the markers to LSL- it 'listens' for messages from the browser that the participant is doing the experiment from, and converts them into 'markers' for your recording software (such as LabRecorder) to receive.

See an example of a full script

from http.server import BaseHTTPRequestHandler, HTTPServer
from urllib.parse import urlparse, parse_qs
from mne_lsl.lsl import StreamInfo, StreamOutlet, local_clock
import threading

# ---------------------------------------------------------------------
# CONFIG
# ---------------------------------------------------------------------
LSL_STREAM_NAME = "jsPsychMarkers"
LSL_STREAM_TYPE = "Markers"
LSL_SOURCE_ID = "jspsych-lsl-bridge"
SERVER_HOST = "0.0.0.0"
SERVER_PORT = 5000
# ---------------------------------------------------------------------

# Create an LSL outlet for event markers
info = StreamInfo(
    name=LSL_STREAM_NAME,
    stype=LSL_STREAM_TYPE,
    n_channels=1,
    sfreq=0,
    dtype="string",
    source_id=LSL_SOURCE_ID,
)

desc = info.desc
desc.append_child_value("manufacturer", "jsPsych")
channels = desc.append_child("channels")
ch = channels.append_child("channel")
ch.append_child_value("label", "JsPsychMarker")
ch.append_child_value("unit", "string")
ch.append_child_value("type", "Marker")

outlet = StreamOutlet(info)

# ---------------------------------------------------------------------
# HTTP Request Handler
# ---------------------------------------------------------------------
class MarkerHandler(BaseHTTPRequestHandler):
    def do_GET(self):
        parsed = urlparse(self.path)
        params = parse_qs(parsed.query)
        path = parsed.path

        if path == "/sync":
            # Return current LSL clock to JS
            ts = local_clock()
            self.send_response(200)
            self.end_headers()
            self.wfile.write(str(ts).encode())

        elif path == "/marker":
            value = params.get("value", ["1"])[0]
            ts_js = params.get("ts", [None])[0]

            if ts_js is not None:
                ts = float(ts_js)
            else:
                ts = local_clock()

            outlet.push_sample([value], ts)
            print(f"→ Marker {value} @ {ts:.6f}")

            self.send_response(200)
            self.end_headers()
            self.wfile.write(b"OK")

        else:
            self.send_response(404)
            self.end_headers()

# ---------------------------------------------------------------------
def run_server():
    server_address = (SERVER_HOST, SERVER_PORT)
    httpd = HTTPServer(server_address, MarkerHandler)
    print(f"\n[LSL Bridge] Serving on http://{SERVER_HOST}:{SERVER_PORT}")
    print(f"[LSL Bridge] Stream '{LSL_STREAM_NAME}' ready for LabRecorder.\n")
    httpd.serve_forever()

# ---------------------------------------------------------------------
if __name__ == "__main__":
    server_thread = threading.Thread(target=run_server)
    server_thread.start()

Configuration of the Python Script

  1. Set-up
  1. Create the LSL outlet for event triggers
  1. Create the request handler to define what happens when the participant's browser contacts the server.
  1. Run the Server

Configuration of the JsPsych HTML script

See an example of a full script

<!DOCTYPE html\>

<html>

<head>

<title>Black/White Muse Synchronisation Test</title>

<script src="https://unpkg.com/jspsych\@7.3.4"\>\</script\>

<script src="https://unpkg.com/\@jspsych/plugin-html-keyboard-response\@1.1.3"\>\</script\>

<script src="https://unpkg.com/\@jspsych/plugin-image-keyboard-response\@1.1.3"\>\</script\>

<script src="https://unpkg.com/\@jspsych/plugin-preload\@1.1.3"\>\</script\>

<script src="https://unpkg.com/\@jspsych/plugin-fullscreen\@2.1.0"\>\</script\>

<link href="https://unpkg.com/jspsych@7.3.4/css/jspsych.css" rel="stylesheet" />

</head>

<body>

</body>

<script>
// -----------------------
// LSL bridge (promise-based)
// -----------------------
var lslBaseTime = null

function syncLSL() {
    return new Promise(async function (resolve, reject) {
        try {
            let offsets = []
            for (let i = 0; i < 3; i++) {
                var startPerf = performance.now()
                let resp = await fetch("http://139.184.128.202:5000/sync", { cache: "no-store" })
                let text = await resp.text()
                var lslTime = parseFloat(text)
                var endPerf = performance.now()
                var perfMid = (startPerf + endPerf) / 2
                offsets.push(lslTime - perfMid / 1000)
                await new Promise((r) => setTimeout(r, 100)) // Short delay between syncs
            }
            lslBaseTime = offsets.reduce((a, b) => a + b, 0) / offsets.length
            console.log("LSL sync done (averaged):", lslBaseTime)
            resolve(lslBaseTime)
        } catch (e) {
            console.error("LSL sync exception:", e)
            reject(e)
        }
    })
}

function sendMarker(value = "1") {
    // If not synced, still send marker (server will timestamp with local_clock())
    if (lslBaseTime === null) {
        console.warn("LSL not synced yet - sending without JS timestamp")
        fetch("http://139.184.128.202:5000/marker?value=" + encodeURIComponent(value))
            .then(function () {
                console.log("sent marker (no-ts)", value)
            })
            .catch(function (err) {
                console.error("Marker send error:", err)
            })
        return
    }

    var ts = lslBaseTime + performance.now() / 1000
    var url = "http://139.184.128.202:5000/marker?value=" + encodeURIComponent(value) + "&ts=" + encodeURIComponent(ts)
    fetch(url)
        .then(function () {
            console.log("sent marker", value, "ts", ts)
        })
        .catch(function (err) {
            console.error("Marker send error:", err)
        })
}

/* --------------------------
   Experiment Definition
--------------------------- */

function startExperiment() {

    var jsPsych = initJsPsych({
        override_safe_mode: true
    });

    var timeline = [];

    /* preload */
    timeline.push({
        type: jsPsychPreload,
        images: ["white.png", "black.png"]
    });

    /* stimuli */
    var test_stimuli = [
        { stimulus: "white.png", duration: 750, marker: 0 },
        { stimulus: "black.png", duration: 500, marker: 1 }
    ];

    /* trial */
    var test = {
        type: jsPsychImageKeyboardResponse,
        stimulus: jsPsych.timelineVariable("stimulus"),
        trial_duration: jsPsych.timelineVariable("duration"),
        choices: "NO_KEYS",

        data: {
            marker: jsPsych.timelineVariable("marker")
        },

        on_start: function(trial) {
            requestAnimationFrame(() => {
                sendMarker(trial.data.marker);
            });
        }
    };


  var loop_node = {
      timeline: [{
          timeline: [test],
          timeline_variables: test_stimuli,
          randomize_order: false
      }],
      loop_function: function() {
          return jsPsych.getTotalTime() < 2100000;
      }
  };

  timeline.push(loop_node);


    jsPsych.run(timeline);
}

// -----------------------
// Run: first sync then start experiment
// -----------------------
syncLSL()
    .then(function () {
        startExperiment()
    })
    .catch(function (err) {
        console.warn("Proceeding without LSL sync (sync failed):", err)
        startExperiment()
    })

</script>

</html>

The code sending triggers from the browser to the LSL bridge script is written in javascript. It is 'promise-based', meaning it is coded to wait until it receives a signal from the participant's computer. This code is designed to track the exact time it is on the participant's computer and send markers precisely aligned to that time.

  1. Synchronisation
  1. Sending markers

Usage

On the researcher's machine:

  1. Turn off the firewall in security settings for the researcher's machine.
  2. Open the lsl bridge script and go onto the terminal (we use VS code). Type ipconfig to retrieve the ipv4 address.
  3. In the terminal, type pip install mne-lsl.
  4. Select all text in the bridge script and run it (ctrl+a, shift+enter)

On the participant's machine:

  1. Open the html script. You will need to ensure the terminal working directory points towards your experiment folder- the best way to do this is to open your repository folder on VS code.
  2. Copy the ipv4 address from the researcher's machine into the html script- there should be three instances before the :5000 port address.
  3. In a new terminal, run python -m http.server 8000
  4. You are now ready to run the experiment. Go onto your browser and enter the link '<http://localhost:8000/index.html>', adjusting for the name of your html script. Your experiment should now run on the participant's machine. The researcher can view markers received in their python terminal.
